Specifications:
- Operating System: Embedded Linux operation system
- ROM: 16 M, 32 M
- RAM: 256 M
- CPU: Embedded MCU Processor
- Lens: 1
- Resolution: Main stream: 1920 × 1080p, 720p / Sub stream: 704 × 576:
- FOV: Horizontal: 129° Vertical: 75°
- WDR: True WDR
- Supplement Light: IR supplement
- Video Compression Standard: H.264
- Audio Compression Standard: G.711 U
- Audio Input: Built-in omnidirectional microphone
- Audio Output: Built-in loudspeaker
- Audio Compression Bitrate: 64 Kbps
- Audio Quality: Noise suppression and echo cancellation
- Volume Adjustment: Adjustable
- Linked Network Camera Capacity: 1
- Communication Protocol: TCP/IP, RTSP
- Wired Network: 10/100 Mbps self-adaptive Ethernet
- Wi-Fi Standard: Support
- Bluetooth Version: Not supported.
- Received Frequency: 2.4 to 2.4835GHz
- Transmitted Frequency: 2.4 to 2.4835 GHz
- Bandwidth: 20 to 40 MHz
- Frequency Power: 802.11b:16dBm +/- 1.5dBm / 802.11g:15dBm +/- 1.5dBm / 802.11n(ht20):14dBm +/- 1.5dBm / 802.11n(ht40):12dBm +/- 1.5dBm
- Alarm Input: 4
- Network Interface: 1
- TAMPER: 1
- Exit Button: 1
- RS-485: 1
- USB: 0
- Wiegand: 0
- TF Card: 0
- Alarm Output: 0
- Lock Control: 1
- Door Contact Input: 1
- Power Interface: 1
- Multi-Factor Authentication: 2000
- Button: 1
- Surface mounting: 265g
- Protective Level: IP65
- Working Temperature: -40° C to +55° C(-40° F to 131° F)
- Working Humidity: 10% to 95%
- Dimensions: 138 mm × 65 mm × 27 mm
- Indicator: 2
- Application Environment: Outdoor
- Power Consumption: ＜ 10 W
